Smart Substation Enclosure for MV/LV Network Monitoring

Monitor electrical parameters and detect network faults to support maintenance operations.

ACTIA Energy » Solutions » HV/LV Network Monitoring » Smart Substation Enclosure for MV/LV Network Monitoring

REF. CPS-SR-HTABT Categories HV/LV Network Monitoring, Supervision & Monitoring Tags LV, Monitoring

CPS9010

Post Smart Unit Enclosure CPS9035 enables real-time monitoring of HV/LV networks, fault detection and optimisation of interventions.

Post Smart Unit Enclosure is at the heart of our HV/LV network monitoring systems, providing a comprehensive and accurate overview of electrical parameters in real time. It enables rapid detection of malfunctions and optimises maintenance interventions.

Thanks to smart sensors and a dedicated software platform, our Post Smart Enclosure based solutions guarantee continuous service improvement and reduced operating costs.

Key features:

Real-time monitoring of electrical parameters (voltage, current, power, faults)
Detection and location of incidents on the network
Centralised supervision platform with automatic alerts
Compatibility with existing HV/LV infrastructure
Reduction in downtime and optimisation of maintenance

Supervisión de la red eléctrica MT/BT Cuadro Post Smart para la supervisión de redes de MT/BT - ACTIA Energy

Surveillance Réseau HTA/BT Coffret Post Smart pour la Surveillance des Réseaux HTA/BT - ACTIA Energy

This post is also available in: Français Español

Post Smart Unit Enclosure is at the heart of our HV/LV network monitoring systems, providing a comprehensive and accurate overview of electrical parameters in real time. It enables rapid detection of malfunctions and optimises maintenance interventions.

Thanks to smart sensors and a dedicated software platform, our Post Smart Enclosure based solutions guarantee continuous service improvement and reduced operating costs.

Key features:

Real-time monitoring of electrical parameters (voltage, current, power, faults)
Detection and location of incidents on the network
Centralised supervision platform with automatic alerts
Compatibility with existing HV/LV infrastructure
Reduction in downtime and optimisation of maintenance

Features

Intuitive and customizable interface
Detection and signaling of MV current or directional faults
Control of switching devices
Monitoring of the MV and LV network (I, U, P, and Q)
LV measurements, detection of broken MV jumper faults, monitoring of LV voltage waveform quality
Network automation
Substation monitoring (temperatures and water levels)
Battery, power unit
Communication with SCADA and others via 4G/Radio router, IEC 60870-5-104 protocol

Technical specifications

Cybersecurity: Hardening, Encryption, Enrollment...
Reduction of outages and cost optimization
Rapid detection of network incidents
Improved quality of service

Applications

Electrical infrastructure management
Optimisation of HV/LV networks
Preventive and corrective maintenance

Brochure

COFFRET-POST-SMART-E1-FP-FR

COFFRET-POST-SMART-E1-FP-FR
